A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

3-335

Nur für den internen Gebrauch Boards for HiPath 3000

Peripheral boards

Contact assignment

Note: Pinouts shown are at the board itself. The main distribution frame cable (MDF cable)

supplied reverses the signal order before the MDF.

Table 3-164 TMGL4 (for U.S. only) - Contact Assignment

Contact Connector X2 Port

1 b-wire (ring), trunk 1 1

2 a-wire (tip), trunk 1

3 b-wire (ring), trunk 2 2

4 a-wire (tip), trunk 2

5 b-wire (ring), trunk 3 3

6 a-wire (tip), trunk 3

7 b-wire (ring), trunk 4 4

8 a-wire (tip), trunk 4
