boards.fm

A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

3-387

Nur für den internen Gebrauch Boards for HiPath 3000

Options

blk/gry 27 RK4 15a

gry/blk 26 0 V 15b

yel/blu 24 PFTTSb 16a

ALUM: Subscriber line

module

blu/yel 23 PFTTSa 16b

yel/ora 58 – 17a

ora/yel 57 S5 17b

yel/grn 56 0 V 18a

grn/yel 55 – 18b

yel/brn 54 – 19a

brn/yel 53 S3 19b

yel/gry 52 S4 20a

gry/yel 51 0 V 20b

vio/blu 50 UK1 21a Relay 1: Switch contact

blu/vio 49 UK2 21b Relay 2: Switch contact

vio/ora 48 UK3 22a Relay 3: Switch contact

ora/vio 47 UK4 22b Relay 4: Switch contact

vio/grn 46 0 V 23a

grn/vio 45 – 23b

vio/brn 44 – 24a

brn/vio 43 S6 24b

1 see “Abbreviations for colors“ at the start of Section 3.4.

Table 3-183 REALS - SIVAPAC Connector Assignment on the Backplane

Pair

a-wire

(tip)

b-wire

(ring)1

SIVAPAC Connec-

tor X116

REALS MDFU-E Notes
