Boards for HiPath 3000 Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

3-392 HiPath 3000/5000 V9, Service documentation

boards.fm

Options

STRB and STRBR Board Relay and Sensor Functions

Figure 3-150 STRB and STRBR Board Relay and Sensor Functions

STRB or STRBR

K1.21

K1.22

K1.23

K1.11

K1.12

K1.13

Relay

+12 VI+12 V

OPTKP1

To system

Short the wires to activate the

sensor.

Sensor
