inst_h3.fm

A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

4-71

Nur für den internen Gebrauch Installing HiPath 3000

Installing HiPath 3800

Color Codes for the Open-End Cable

Table 4-8 Color codes for the open-end cable

Color Group Pair a-wire

(tip)

b-wire

(ring)

Color Group Pair a-wire

(tip)

b-wire

(ring)

1 1 wht/blu 4 16 yel/blu

blu/wht blu/yel

2 wht/ora 17 yel/ora

ora/wht ora/yel

3 wht/grn 18 yel/grn

grn/wht grn/yel

4 wht/brn 19 yel/brn

brn/wht brn/yel

5 wht/gry 20 yel/gry

gry/wht gry/yel

2 6 red/blu 5 21 vio/blu

blu/red blu/vio

7 red/ora 22 vio/ora

ora/red ora/vio

8 red/grn 23 vio/grn

grn/red grn/vio

9 red/brn 24 vio/brn

brn/red brn/vio

10 red/gry Note: In the case of cables with 16 double

wires, the specifications for pairs 17 to 24 are

not relevant.

gry/red

3 11 blk/blu

blu/blk

12 blk/ora

ora/blk

13 blk/grn

grn/blk

14 blk/brn

brn/blk

15 blk/gry

gry/blk
