HiPath 3000
Boards for Tie Trunk Traffic
TMC16 16 - x Analog trunk board (ground/loop start)
TM2LP 8 x x Board with 8 ports to connect LS trunk connections and
enables CAS trunk connections
1 TMCAS-2: For selected countries only
2 DIUT2: Up to 3 DIUT2 and/or DIUN2 per system. Up to 4 DIUT2 and/or DIU2U per system when used as T1 trunk connection.
3 TMDID2: For selected countries only
Table 2-8 Tie Trunk Traffic Boards for HiPath 3800
Board
Name
Capacity Coun-
try
Type/Description
Ports per board
B channels per board
Boards per cabinet
Max. number of
boards per system
ROW
USA
DIUN2 60 60 3 x Board for primary rate access.
In HiPath 3000/HiPath 5000 V5.0 and later, the B chan-
nels in the DIUN2 board must be licensed.
DIUT2 60 60 3 x x Board for S
2M
networking.
The B channels associated with the DIUT2 board re-
quire a license.
Table 2-7 Trunk Boards for HiPath 3800
Board
Name
Capacity Coun-
try
Type/Description
Ports per board
B channels per board
Boards per cabinet
Max. number of
boards per system
ROW
USA
