HiPath 3000/5000 V9, Service documentation

8-21

Nur für den internen Gebrauch Licensing

Licensing Scenarios

10. Details on the selected license key are displayed:

● “Display” tab: Type and number of licensed features, customer-specific informa-

tion.

● “Transactions” tab: Actions performed for each feature

11. Select Download.

In the subsequent dialog, specify the storage location for the license key you want to

download.

Section 8.2.4 describes the procedure for distributing licenses with HiPath 3000/5000

Manager E.

Step Activity (Remarks)
