Expanding and Upgrading HiPath 3000 Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

9-20 HiPath 3000/5000 V9, Service documentation

exup.fm

HiPath 3000Expanding

6. Remove the mounting screw [A] on the battery retainer [B].

7. Remove the battery retainer and set aside.

8. Insert the battery carefully and connect it: To do this, slide the eight cable connec-

tor lugs [D] carefully onto the two connection contacts on each of the four batter-

ies.

Step Activity

[A]

[B]

[D]
