Workpoint Clients Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
10-8 HiPath 3000/5000 V9, Service documentation
wclient.fm
OpenStage Product Family
10.1.2.2 OpenStage 15
Product image
Figure 10-2 OpenStage 15
Main features
Feature Description
Display LCD, immobile, two lines, monochrome, 24 x 2 characters
Pre-programmed func-
tion keys
● Three audio keys for:
– decreasing the volume and brightening the display contrast
– activating/deactivating the loudspeaker
– increasing the volume and darkening the display contrast
● Mailbox key for checking voicemail
● Menu key for the communication system’s Service menu
Dialing keypad For entering digits 0 to 9, pound and asterisk symbols, letters, punc-
tuation marks and special characters
Navigation keys Three keys for:
● scrolling forward through the menu or opening the idle menu
● executing actions
● scrolling back through the menu or opening the idle menu
