Workpoint Clients Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

10-86 HiPath 3000/5000 V9, Service documentation

wclient.fm

optiPoint 500

Standard key assignment (default) for optiPoint 500 standard

Refer to Section 10.5.1.6 for connection requirements.

Figure 10-39 optiPoint 500 standard - Standard Key Assignment (Default)

Service Programmable

Redial Programmable

Microphone on/off Programmable

Loudspeaker Programmable

Programmable

Disconnect
