Workpoint Clients Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

10-88 HiPath 3000/5000 V9, Service documentation

wclient.fm

optiPoint 500

Standard key assignment (default) for optiPoint 500 advance

Refer to Section 10.5.1.6 for connection requirements.

Figure 10-40 optiPoint 500 advance - Standard Key Assignment (Default)

Service Programmable

Redial Programmable

Microphone on/off Programmable

Loudspeaker Programmable

Programmable

Disconnect
