Siemens Hipath 5000 Service Documentation

Workpoint Clients Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
10-102 HiPath 3000/5000 V9, Service documentation
wclient.fm
optiPoint 500
Table 10-7 Floating contacts on the optiPoint acoustic adapter
Pin Assign-
ment
Notes
1Free –
2 “Busy” con-
tact
Signals active telephone states:
● handset lifted
● Loudspeaker activated or headset active
These states can be displayed, for example, on external signaling equip-
ment (LED, relay, etc.) The signaling equipment must have its own power
supply.
The contact can be loaded with up to 5 W at 24 Vac or 60 VDC.
3
4 “Call” con-
tact
Signals the call receipt state.
This can be used, for example, to control a secondary bell.
The contact can be loaded with up to 5 W at 24 Vac or 60 VDC.
5
6Free –
