Workpoint Clients Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

10-110 HiPath 3000/5000 V9, Service documentation

wclient.fm

optiPoint Accessories

Example: External AC Adapter Connection

Table 10-10 Pin Assignment for Local Power Supply AUL:06D1284 (Euro)

Pin Assignment

1 Not used

2–

3 a-wire (tip)

4 b-wire (ring)

6 Not used

Figure 10-53 Example: External AC Adapter Connection

Power supply

“MW”

(RJ) jack

jack

“Digital”

from the optiPoint 500 ad-

apter (for example, here,

optiPoint analog adapter)

Analog

tele-

phone or

optiPoint 500

telephone

HiPath 3xx0
