HiPath Cordless Office Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

11-10 HiPath 3000/5000 V9, Service documentation

cordless.fm

Multi-SLC and System-Wide Networking

Networked HiPath 3000 systems feature

● max. 64 networked systems

● accessible using a shared station number (roaming among the systems/nodes)

● call interruption when changing between systems/nodes

Figure 11-3 Example: Cordless Extension Connection in Networked Systems

SLC

CorNet NQ

Home SLC

SLC-No. = 1

Station no = 124

Current location

SLC

SLC-No. = 11

Station no = 128

HiPath 3000

System 1

HiPath 3000

System 2

Extension

connection

SLC

SLC-No. = 2

Station number =

141

SLC

BS = BS3/1 or BS3/

A CorNet NQ connection is possible using S

or S

lines or IP networking (see HG 1500 Administration

Manual).
