Siemens SIMATIC ET 200X - Page 280

Technical Specifications
7-92
ET 200X Distributed I/O Device
EWA 4NEB 780601602-06
Tables for output ranges
As of Table 7-48 you will find the analog output ranges of the expansion modules
with analog outputs.
Output ranges 10 V 20 mA
The following table contains the representation of the output ranges for the:
 For the voltage output range  10 V and
 For the current output range  20 mA.
Table 7-48 SIMATIC S7 format: representation of the analog output range +/–10 V;
+/–20 mA
Output range

Output range

Units
 10 V  20 mA
Decimal Hexadecimal
Range
0 0 >32511 >7EFF
H
Overflow
11.7589 23.515 32511 7EFF
H
: : : :
Overrange
10.0004 20.0007 27649 6C01
H
10.00 20.000 27648 6C00
H
7.50 14.998 20736 5100
H
: : : : Rated range
– 7.50 – 14.998 –20736 AF00
H
– 10.00 – 20.000 –27648 9400
H
– 10.0004 –20.0007 –27649 93FF
H
: : : :
Underrange
– 11.7589 – 23.515 –32512 8100
H
0 0 <–32512 <8100
H
Underflow
