Technical Specifications
7-93
ET 200X Distributed I/O Device
EWA 4NEB 780601602-06
Output range 4 to 20 mA
The following table contains the representation of the current output range 4 to
20 mA.
Table 7-49 SIMATIC S7 format: representation of the analog current output range 4 to
20 mA
Output range Units Range
4 to 20 mA
Decimal Hexadecimal
0 >32511 >7EFF
H
Overflow
22.8142 32511 7EFF
H
: : :
Overrange
20.0005 27649 6C01
H
20.000 27648 6C00
H
: : :
Rated range
4.000 0 0
H
3.9995 –1 FFFF
H
: : :
Underrange
0 – 6912 E500
H
0 <–6913 <E4FF
H
Underflow
