Tables for output ranges
As of Table 7-56 you will find the analog output ranges of the expansion modules
with analog outputs.
Output range  10 V
The following table contains the representation of the voltage output range  10 V.
Table 7-56 SIMATIC S5 format: representation of the analog voltage output range +/–10 V
Output
Units Data word Range
range
 10 V
(dec.)
2
11
2
10
2
9
2
8
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
x xxx
0 1205 0 1 0 0 1 0 1 1 0 1 0 1 x x x x Overflow
11.7578 1204 0 1 0 0 1 0 1 1 0 1 0 0 x x x x Overrange
10.0098 1025 0 1 0 0 0 0 0 0 0 0 0 1 x x x x
10.0000 1024 0 1 0 0 0 0 0 0 0 0 0 0 x x x x
0.0098 1 0 0 0 0 0 0 000001xxxx
0.000 0 0 0 0 0 0 0 000000xx x x Rated
–0.0098 –1 1 1 1 1 1 1 111111xxxx
range
–10.0000 –1024 1 1 0 0 0 0 000000xxxx
–10.0098 –1025 1 0 1 1 1 1 1 1 1 1 1 1 x x x x Under-
–11.7578 –1204 1 0 1 1 0 1 0 0 1 1 0 0 x x x x
range
0 1205 1 0 1 1 0 1 0 0 1 0 1 1 x x x x Underflow
