6.10 Linear motors (1FN1 and 1FN3 motors)
6-146
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
Note
The outer and inner shielding of the signal lines in the power cable and the
shielding for the temperature sensor coupling lead MUST be laid flat on the
shielding connecting plate.
Failure to connect the shield correctly can result in high touch voltages, mal-
functions and sporadic errors or irreparable damage to the closed-loop control
module.
Table 6-28 Assignments of temperature sensor coupling lead
Signal Power cable Temperature sensor coupling lead
(dongle)
–X411
on drive
Temperature sensor + Black core Brown + black core Pin 13
Temperature sensor – White core Orange + red core Pin 25
Temperature switch/PTC
Yellow core
– –
Temperature switch/PTC Red core – –
