6.12 System settings for power-up, RESET and starting part programs
6-157
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
S after start of part program
MD 20112: START_MODE_MASK, Bit 4–10 = 0 or 1
Bits 4 – 10 may be combined as required.
Start of part program
MD 20112
START_MODE_MASK
Bit 4 – 10
Bit 4–10
= 0
Bit 4–10= 1
The current settings are
retained in relation to
– current level
– current variable frame
– active tool offset
– active transformation
– coupled units
– tangential adjustment
– non-configured synchronous spindle
coupling
The current settings are reset in relation to:
– current level
– current variable frame
– active tool offset
– active transformation
– coupled units
– tangential adjustment
– non-configured synchronous spindle coupling
Fig. 6-48 System settings after start of part program
Reference material: /FB1/ K2, Functional description of the basic machines,
Axes, coordinate systems, frames,
Section: Actual value system in vicinity of
workpiece
