For Safety Integrated, the signals with fixed bit names are supplemented with
the following signals, whose names can be defined/redefined by the user:
Table 10-2 SI signals with variable bit identifiers
SI signal German
Bit
Identifier English
ext. NCK–SPL interface inputs 0..31 EXT_NCK_SPL_INPUT_0
...
EXT_NCK_SPL_INPUT_31
32..63 EXT_NCK_SPL_INPUT_32
...
EXT_NCK_SPL_INPUT_63
ext. NCK–SPL interface outputs 0..31 EXT_NCK_SPL_OUTPUT_0
...
EXT_NCK_SPL_OUTPUT_31
32..63 EXT_NCK_SPL_OUTPUT_32
...
EXT_NCK_SPL_OUTPUT_63
int. NCK–SPL interface inputs 0..31 INT_NCK_SPL_INPUT_0
...
INT_NCK_SPL_INPUT_31
32..63 INT_NCK_SPL_INPUT_32
...
INT_NCK_SPL_INPUT_63
int. NCK–SPL interface outputs 0..31 INT_NCK_SPL_OUTPUT_0
...
INT_NCK_SPL_OUTPUT_31
32..63 INT_NCK_SPL_OUTPUT_32
...
INT_NCK_SPL_OUTPUT_63
ext. PLC–SPL interface inputs 0..31 EXT_PLC_SPL_INPUT_0
...
EXT_PLC_SPL_INPUT_31
32..63 EXT_PLC_SPL_INPUT_32
...
EXT_PLC_SPL_INPUT_63
ext. PLC–SPL interface outputs
0..31
EXT_PLC_SPL_OUTPUT_0
...
EXT_PLC_SPL_OUTPUT_31
32..63 EXT_PLC_SPL_OUTPUT_32
...
EXT_PLC_SPL_OUTPUT_63
int. PLC–SPL interface inputs 0..31 INT_PLC_SPL_INPUT_0
...
INT_PLC_SPL_INPUT_31
32..63 INT_PLC_SPL_INPUT_32
...
INT_PLC_SPL_INPUT_63
int.PLC–SPL interface outputs 0..31 INT_PLC_SPL_OUTPUT_0
...
INT_PLC_SPL_OUTPUT_31
32..63 INT_PLC_SPL_OUTPUT_32
...
INT_PLC_SPL_OUTPUT_63
User
bit names
