10.9 Automatic controller settings ( HMI Advanced only)
10-220
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
1
2
Start
mech. system
measurement
part 2?
SK “OK”
Prompt to press NC-Start
Warning:
Pressing NC-Start causes the axis
to perform a traversing motion.
SK “Parameter”
Enter the
measuring
parameters
SK “Abort”
(discard
changes)
SK “OK”
(accept
values)
Start
current control loop
measurement?
SK “OK”
Prompt to press NC-Start
Warning:
Pressing NC-Start operates the
axis controlled by the current.
SK “Parameter”
Enter the
measuring
parameters
SK “Abort”
(discard
changes)
SK “OK”
(accept
values)
10 Drive O
p
timization
