Siemens SINUMERIK 840D Simodrive 611 digital - Page 275

12
03/2006
12.4 Standard system start-up via NC card
12-275
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
1. Start the “sinucopy-ffs.exe” file
2. Enter the password
3. Dialog: Specify a temporary directory for unzipping the files
4. Dialog: Specify the hardware configuration
5. Dialog: Select the components to be installed
6. Dialog: Specify a directory for the installation
7. The SW is installed
8. Message: “driver installed”
9. Dialog: “Select the name of the program folder”
10. Dialog: Please read the README file
11. Dialog: Restart now or later
12. Following restart, you can use the SINUCOPY-FFS function
This tool is intended for use by experts.
S Read archive data
S Delete/insert files
S Modify files (if editable)
This tool is intended for use by experts.
S Read and write NC cards
S Duplicate NC cards
Note
1. PG with SINUCOPY (previous version)
The installation can fail if the driver “cisio-s” is entered in the “config.sys” file
and this is detected during power up: error message. Remedy:
– Delete the line “Device ...cisio.exe, cisio.ini”.
– Enter a free interrupt number in HEX format in the “cisio.ini” file in the
line IRQ=....
A free interrupt number can be determined via the “System properties”
menu of the “Device manager”.
2. If an NC card with FFS is copied with previous version of SINUCOPY, only
the NC system (not the FFS part) is transferred to the copy.
3. Any drive may be designated for the OMNI97 device: Simply enter the drive
letter in the “Control Panel/Device Manager/Drives/OMNI97” menu.
Windows NT: Enter the drive letter in the “OmniControl/DriveLetter” menu.
Installation
Tool: ARCEDIT
Tool: SICARD
12 Re
p
lacin
g
Software and Hardware
