Siemens SINUMERIK 840D Simodrive 611 digital - Page 74

6 Pro
g
rammin
g
the control
6
03/2006
6.7 Memory configuration
6-74
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
If the NCU is used with a larger memory, this memory must be enabled.
S Enter the value 1900 in MD 18230: MM_USER_MEM_BUFFERED.
S Stream off a standard system start-up file.
S POWER ON (to reorganize the memory).
S Download the standard system start-up file to the control once more.
MD 18060 shows how much RAM is still free.
Recommendation:
Values > 15000 should be displayed so that data (e.g. tool offsets) can be read
in at any time.
Note
For normal applications, leave all other memory settings unchanged.
Changing the following machine data causes the control SRAM to be
reconfigured. In the event of a change, the “4400 MD change caused
reorganisation of the buffered memory (data lost!)” alarm is output. When this
alarm is output, all data must be saved because all buffered user data will be
erased during the next booting.
Table 6-13 Machine data for the memory configuration
MD Number MD name Meaning
MD 18020 MM_NUM_GUD_NAMES_NCK Number of global user variables
MD 18030 MM_NUM_GUD_NAMES_CHAN Number of global user variables
MD 18080 MM_TOOL_MANAGEMENT_MASK Tool management memory
MD 18082 MM_NUM_TOOL Number of tools
MD 18084 MM_NUM_MAGAZINE Number of magazines
MD 18086 MM_NUM_MAGAZINE_LOCATION Number of magazine locations
MD 18090 MM_NUM_CC_MAGAZINE_PARAM Number of magazine data items
MD 18092 MM_NUM_CC_MAGLOC_PARAM Number of magazine location data items
MD 18094 MM_NUM_CC_TDA_PARAM Number of tool-specific data items
MD 18096 MM_NUM_CC_TOA_PARAM Number of TOA data items
MD 18098 MM_NUM_CC_MON_PARAM Number of monitoring data items
MD 18100 MM_NUM_CUTTING_EDGES_IN_TOA Number of cutting edges per TOA block
MD 18110 MM_NUM_TOA_MODULES Number of TOA blocks
MD 18118 MM_NUM_GUD_MODULES Number of GUD files
MD 18120 MM_NUM_GUD_NAMES_NCK Number of global user variables
MD 18130 MM_NUM_GUD_NAMES_CHAN Number of channel-specific user variables
MD 18140 MM_NUM_GUD_NAMES_AXIS Number of axis-specific user variables
MD 18150 MM_GUD_VALUES_MEM Memory location for user variables
MD 18160 MM_NUM_USER_MACROS Number of macros
SRAM with
2 MB module
Check SRAM
Deleting SRAM by
changing the MD
