6.7 Memory configuration
6-75
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
Table 6-13 Machine data for the memory configuration
MD Number MeaningMD name
MD 18190 MM_NUM_PROTECT_AREA_NCKC Number of protected areas
MD 18230 MM_USER_MEM_BUFFERED RAM in SRAM
MD 18270 MM_NUM_SUBDIR_PER_DIR Number of subdirectories
MD 18280 MM_NUM_FILES_PER_DIR Number of files
MD 18290 MM_FILE_HASH_TABLE_SIZE Hash table size for files in a directory
MD 18300 MM_DIR_HASH_TABLE_SIZE Hash table size for subdirectories
MD 18310 MM_NUM_DIR_IN_FILESYSTEM Number of directories in the passive file system
MD 18320 MM_NUM_FILES_IN_FILESYSTEM Number of files in the passive file system
MD 18330 MM_CHAR_LENGTH_OF_BLOCK Max. length of an NC block
MD 18350 MM_USER_FILE_MEM_MINIMUM Minimum RAM in SRAM
MD 28050 MM_NUM_R_PARAM Number of channel-specific R parameters
MD 28080 MM_NUM_USER_FRAMES Number of variable frames
MD 28085 MM_LINK_TOA_UNIT Allocation of a TO unit to a channel
MD 28200 MM_NUM_PROTECT_AREA_CHAN Number of files for protection areas
MD 38000 MM_ENC_COMP_MAX_POINTS [n] Number of interpolating point for interp. compensation
