6.9 Axes and spindles
6-81
© Siemens AG 2006 All Rights Reserved
SINUMERIK 840D/810D Start-Up Guide (IADC) – 03/2006 Edition
The name defined in MD 10000: AXCONF_MACHAX_NAME_TAB or the
associated index is used for:
S Accessing axis-specific machine data (loading, saving, displaying)
S Reference point approach G74
S Measurements
S Test point runs G75
S Traversing commands from PLC
S Display of axis-specific alarms
S Display of actual-value system (machine-related)
S DRF handwheel function
Note
Leading zeros are generally ignored in user-defined axis identifiers.
Examples:
MD 10000: AXCONF_MACHAX_NAME_TAB[0] = X01 corresponds to X1
MD 10000: AXCONF_MACHAX_NAME_TAB[1] = A01 corresponds to A1
MD 10000: AXCONF_MACHAX_NAME_TAB[2] = C01 corresponds to C1
Define axis
identifier
