Table 2-13 Operational measured values (magnitudes) of the sides
Measured Values Primary Secondary % referred to
ΙL1S1, ΙL2S1, ΙL3S1
ΙL1S2, ΙL2S2, ΙL3S2
ΙL1S3, ΙL2S3, ΙL3S3
1)
Phase currents flowing in from the
sides S1 to S3
1)
A; kA — Rated operating current of
the respective side
Ι1S1, Ι2S1, 3Ι0S1
Ι1S2, Ι2S2, 3Ι0S2
Ι1S3, Ι2S3, 3Ι0S3
2)
Positive, negative and zero sequence
component of the currents at the sides
S1 to S3
2)
A; kA — Rated operating current of
the respective side
ΙL1S4, ΙL2S4, ΙL3S4
ΙL1S5, ΙL2S5, ΙL3S5
1) 3)
Phase currents flowing in from the
sides S4 to S5
1) 3)
A; kA — Rated operating current of
the respective side
Ι1S4, Ι2S4, 3Ι0S4
Ι1S5, Ι2S5, 3Ι0S5
2) 3)
Positive, negative and zero sequence
component of the currents at the sides
S4 to S5
2) 3)
A; kA — Rated operating current of
the respective side
1)
only for 3-phase protected objects, also single-phase transformers (not in 7UT612)
2)
only for 3-phase protected objects, not for single-phase transformers (not in 7UT612)
3)
only for 7UT635
The phase angles are listed separately in Table 2-14. The reference value for 3-phase objects is the current
Ι
L1M1
(current in phase L1 at measuring location M1), which has thus a phase angle = 0°. With 1-phase busbar
protection, the current Ι
1
has the phase angle 0°, i.e. it is the reference value.
Depending on the device’s order number, connection type, topology and protection functions configured, only
a part of the phase angles listed there is available.
Phase angles are indicated in degrees. Since further processing of such values (in CFC or when transmitted
through serial interfaces) requires values without dimension, arbitrary references have been chosen, which
are contained in Table 2-14 in the column “% Conversion”.
Table 2-14
Operational measured values (phase relationship)
Measured Values Dimension
% Conversion
6)
φΙL1M1, φΙL2M1, φΙL3M1
φΙL1M2, φΙL2M2, φΙL3M2
φΙL1M3, φΙL2M3, φΙL3M3
1)
Phase angle of the currents at the measuring
locations M1 to M3, referred to ΙL1 M1
1)
˚
0˚ = 0 %
360˚ = 100 %
φΙL1M4, φΙL2M4, φΙL3M4
φΙL1M5, φΙL2M5, φΙL3M5
1) 5)
Phase angle of the currents at the measuring
locations M1 to M3, referred to ΙL1M1
1) 5)
˚ 0˚ = 0 %
360˚ = 100 %
φΙX1; φΙX2; φΙX3
Currents at the 1-phase further measuring loca-
tions X1 to X3, referred to ΙL1M13
˚ 0˚ = 0 %
360˚ = 100 %
φΙX4
5)
Currents at the 1-phase auxiliary measuring loca-
tion X4, referred to ΙL1M1
5)
˚ 0˚ = 0 %
360˚ = 100 %
φΙ1 to φΙ9
3)
Phase angle of the currents at the current inputs,
referred to Ι1
3)
˚ 0˚ = 0 %
360˚ = 100 %
φΙ10 to φΙ12
3) 5)
Phase angle of the currents at the current inputs,
referred to Ι1
3) 5)
˚ 0˚ = 0 %
360˚ = 100 %
φUL1E; φUL2E; φUL3E
1) 4)
Phase angle of the voltages at the 3-phase
voltage measuring location, referred to ΙL1M1
bzw. Ι1
1) 4)
˚ 0˚ = 0 %
360˚ = 100 %
φUen
4)
Phase angle of the voltages at the 1-phase
voltage measuring location, referred toΙL1M1
bzw. Ι1
4)
˚ 0˚ = 0 %
360˚ = 100 %
φU4
4)
Phase angle of the voltages at the 1-phase
voltage measuring location, referred to ΙL1M1
bzw. Ι1
4)
˚ 0˚ = 0 %
360˚ = 100 %
Functions
2.22 Auxiliary Functions
SIPROTEC 4, 7UT6x, Manual 281
C53000-G1176-C230-5, Edition 09.2016
