No. Information Type of
Informa-
tion
Comments
30641 I1S1= MV I1 (positive sequence) of side 1
30642 I2S1= MV I2 (negative sequence) of side 1
30643 3I0S2= MV 3I0 (zero sequence) of side 2
30644 I1S2= MV I1 (positive sequence) of side 2
30645 I2S2= MV I2 (negative sequence) of side 2
30646 I1= MV Operat. meas. current I1
30647 I2= MV Operat. meas. current I2
30648 I3= MV Operat. meas. current I3
30649 I4= MV Operat. meas. current I4
30650 I5= MV Operat. meas. current I5
30651 I6= MV Operat. meas. current I6
30652 I7= MV Operat. meas. current I7
30653 I8= MV Operat. meas. current I8
30656 Umeas.= MVU Operat. meas. voltage Umeas.
30661 IL1M1= MV Operat. meas. current IL1 meas. loc. 1
30662 IL2M1= MV Operat. meas. current IL2 meas. loc. 1
30663 IL3M1= MV Operat. meas. current IL3 meas. loc. 1
30664 3I0M1= MV 3I0 (zero sequence) of meas. loc. 1
30665 I1M1= MV I1 (positive sequence) of meas. loc. 1
30666 I2M1= MV I2 (negative sequence) of meas. loc. 1
30667 IL1M2= MV Operat. meas. current IL1 meas. loc. 2
30668 IL2M2= MV Operat. meas. current IL2 meas. loc. 2
30669 IL3M2= MV Operat. meas. current IL3 meas. loc. 2
30670 3I0M2= MV 3I0 (zero sequence) of meas. loc. 2
30671 I1M2= MV I1 (positive sequence) of meas. loc. 2
30672 I2M2= MV I2 (negative sequence) of meas. loc. 2
30673 IL1M3= MV Operat. meas. current IL1 meas. loc. 3
30674 IL2M3= MV Operat. meas. current IL2 meas. loc. 3
30675 IL3M3= MV Operat. meas. current IL3 meas. loc. 3
30676 3I0M3= MV 3I0 (zero sequence) of meas. loc. 3
30677 I1M3= MV I1 (positive sequence) of meas. loc. 3
30678 I2M3= MV I2 (negative sequence) of meas. loc. 3
30679 IL1M4= MV Operat. meas. current IL1 meas. loc. 4
30680 IL2M4= MV Operat. meas. current IL2 meas. loc. 4
30681 IL3M4= MV Operat. meas. current IL3 meas. loc. 4
30682 3I0M4= MV 3I0 (zero sequence) of meas. loc. 4
30683 I1M4= MV I1 (positive sequence) of meas. loc. 4
30684 I2M4= MV I2 (negative sequence) of meas. loc. 4
30685 IL1M5= MV Operat. meas. current IL1 meas. loc. 5
30686 IL2M5= MV Operat. meas. current IL2 meas. loc. 5
30687 IL3M5= MV Operat. meas. current IL3 meas. loc. 5
30688 3I0M5= MV 3I0 (zero sequence) of meas. loc. 5
30689 I1M5= MV I1 (positive sequence) of meas. loc. 5
30690 I2M5= MV I2 (negative sequence) of meas. loc. 5
30713 3I0S3= MV 3I0 (zero sequence) of side 3
Functions
2.22 Auxiliary Functions
SIPROTEC 4, 7UT6x, Manual 283
C53000-G1176-C230-5, Edition 09.2016
