Siemens SIPROTEC 4 7UT6 Series User Manual

No. Information Type of
Informa-
tion
Comments
30714 I1S3= MV I1 (positive sequence) of side 3
30715 I2S3= MV I2 (negative sequence) of side 3
30716 IL1S4= MV Operat. meas. current IL1 side 4
30717 IL2S4= MV Operat. meas. current IL2 side 4
30718 IL3S4= MV Operat. meas. current IL3 side 4
30719 3I0S4= MV 3I0 (zero sequence) of side 4
30720 I1S4= MV I1 (positive sequence) of side 4
30721 I2S4= MV I2 (negative sequence) of side 4
30722 IL1S5= MV Operat. meas. current IL1 side 5
30723 IL2S5= MV Operat. meas. current IL2 side 5
30724 IL3S5= MV Operat. meas. current IL3 side 5
30725 3I0S5= MV 3I0 (zero sequence) of side 5
30726 I1S5= MV I1 (positive sequence) of side 5
30727 I2S5= MV I2 (negative sequence) of side 5
30728 IX1= MV Operat. meas. auxiliary current IX1
30729 IX2= MV Operat. meas. auxiliary current IX2
30730 IX3= MV Operat. meas. auxiliary current IX3
30731 IX4= MV Operat. meas. auxiliary current IX4
30732 I9= MV Operat. meas. current I9
30733 I10= MV Operat. meas. current I10
30734 I11= MV Operat. meas. current I11
30735 I12= MV Operat. meas. current I12
30736 φIL1M1= MV Phase angle in phase IL1 meas. loc. 1
30737 φIL2M1= MV Phase angle in phase IL2 meas. loc. 1
30738 φIL3M1= MV Phase angle in phase IL3 meas. loc. 1
30739 φIL1M2= MV Phase angle in phase IL1 meas. loc. 2
30740 φIL2M2= MV Phase angle in phase IL2 meas. loc. 2
30741 φIL3M2= MV Phase angle in phase IL3 meas. loc. 2
30742 φIL1M3= MV Phase angle in phase IL1 meas. loc. 3
30743 φIL2M3= MV Phase angle in phase IL2 meas. loc. 3
30744 φIL3M3= MV Phase angle in phase IL3 meas. loc. 3
30745 φIL1M4= MV Phase angle in phase IL1 meas. loc. 4
30746 φIL2M4= MV Phase angle in phase IL2 meas. loc. 4
30747 φIL3M4= MV Phase angle in phase IL3 meas. loc. 4
30748 φIL1M5= MV Phase angle in phase IL1 meas. loc. 5
30749 φIL2M5= MV Phase angle in phase IL2 meas. loc. 5
30750 φIL3M5= MV Phase angle in phase IL3 meas. loc. 5
30751 φIX1= MV Phase angle in auxiliary current IX1
30752 φIX2= MV Phase angle in auxiliary current IX2
30753 φIX3= MV Phase angle in auxiliary current IX3
30754 φIX4= MV Phase angle in auxiliary current IX4
30755 φI8= MV Phase angle of current I8
30756 φI9= MV Phase angle of current I9
30757 φI10= MV Phase angle of current I10
30758 φI11= MV Phase angle of current I11
Functions
2.22 Auxiliary Functions
284 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
