Siemens SIPROTEC 4 7UT6 Series User Manual

The device also checks the matching factors between the rated currents of the CT’s and the operational
currents of the protected object(s) as processed by the protection functions. If very high deviations combined
with sensitive protection settings are discovered an alarm is output which also indicates the suspicious setting
address(es).
In the operational or spontaneous annunciations also check if there are any fault annunciations from the
device.
Table 3-29 Indications on inconsistencies
Message No. Meaning see
Section
Error1A/
5Awrong
192 Setting of the rated secondary currents on input/output board incon-
sistent, general
2.1.4 Power
System Data
1
3.1.2 Hard-
ware Modifi-
cations
(“Switch
elements”)
Err. IN CT M1
to
Err. IN CT M5
30097
to
30101
Setting of the rated secondary currents inconsistent for the indicated
measured current input (3-phase inputs)
2.1.4 Power
System Data
1
3.1.2 Hard-
ware Modifi-
cations
(“Switch
elements”)
Err.IN CT1..3
to
Err.IN
CT10..12
30102
to
30105
Setting of the rated secondary currents inconsistent for the indicated
measured current input (inputs for single-phase busbar protection)
2.1.4 Power
System Data
1
3.1.2 Hard-
ware Modifi-
cations
(“Switch
elements”)
Err. IN CT IX1
to
Err. IN CT IX4
30106
to
30109
Setting of the rated secondary currents inconsistent for the indicated
measured current input (single-phase inputs)
2.1.4 Power
System Data
1
3.1.2 Hard-
ware Modifi-
cations
(“Switch
elements”)
FaultConfig/Se
t
311 Group indication for configuration error
GenErrGroup-
Conn
312 General: Error in transformer connection group 2.1.4 Power
System Data
1
GenErrEarthCT
313 Error in single-phase inputs for earth fault differential protection 2.1.4 Power
System Data
1
GenErrSides-
Meas
314 Error in assignment of sides and/or measuring locations 2.1.4 Power
System Data
1
par too low:
30067 Parameter setting value too small for the indicated address number
Mounting and Commissioning
3.3 Commissioning
360 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
