Message No. Meaning see
Section
par too high:
30068 Parameter setting value too high for the indicated address number
settingFault:
30069 Parameter setting implausible for the indicated address number
Diff
Adap.fact.
5620 The matching factor of the current transformers for the differential
protection is too great or too small
2.1.4 Power
System Data
1
2.2 Differen-
tial Protec-
tion
Diff err. Set.
5623 Differential protection setting not plausible 2.2 Differen-
tial Protec-
tion
REF Not avail. 199.2491 Restricted earth fault protection is not available for the configured
protected object
2.1.4 Power
System Data
1
REF Adap.fact. 199.2494 The matching factor of the current transformers for restricted earth
fault protection is too great or too small.
2.1.4 Power
System Data
1
2.3 Restricte
d Earth Fault
Protection
REF Err CTstar 199.2492 There is no single-phase measuring input assigned to the starpoint
current for restricted earth fault protection
2.1.4 Power
System Data
1
2.2 Differen-
tial Protec-
tion
REF2 Not avail. 205.2491 Restricted earth fault protection 2 is not available for the configured
protected object
2.4.1 Gener
al
REF2 Adap.fact. 205.2494 The matching factor of the current transformers for restricted earth
fault protection 2 is too great or too small.
2.4.1 Gener
al
2.3 Restricte
d Earth Fault
Protection
REF2 Err CTstar 205.2492 There is no single-phase measuring input assigned to the starpoint
current for restricted earth fault protection 2
2.4.1 Gener
al
2.2 Differen-
tial Protec-
tion
O/C Ph. Not av. 023.2491 Time overcurrent protection for phase currents is not available for the
configured protected object
2.1.4 Power
System Data
1
O/C Ph2 Not av. 207.2491 Time overcurrent protection for phase currents 2 is not available for
the configured protected object
2.1.4 Power
System Data
12.1.6 Powe
r System
Data 2
O/C Ph3 Not av. 209.2491 Time overcurrent protection for phase currents 3 is not available for
the configured protected object
2.1.4 Power
System Data
12.1.6 Powe
r System
Data 2
Mounting and Commissioning
3.3 Commissioning
SIPROTEC 4, 7UT6x, Manual 361
C53000-G1176-C230-5, Edition 09.2016
