Message No. Meaning see
Section
Pf> VT error
5131 Forward power supervision is not available without voltage connec-
tion
2.13 Forwar
d Power
Supervision
Pf> set error
5133 Forward power supervision setting not plausible 2.13 Forwar
d Power
Supervision
BkrFail Not av. 047.2491 Breaker failure protection is not available for the configured protected
object
2.1.4 Power
System Data
1
BkrFail2 Not av 206.2491 Breaker failure protection 2 is not available for the configured
protected object
2.1.4 Power
System Data
12.1.6 Powe
r System
Data 2
TripC ProgFail
6864 For trip circuit supervision the number of binary inputs was set incor-
rectly
3.1 Mountin
g and
Connections
(“Connec-
tion
Variants“)”)
Check in the operational or spontaneous annunciations that there is not any information on inconsistencies.
The matching factors of all measured value inputs are indicated in the operational annunciations. It is recom-
mended to check these factors even if none of the above mentioned alarms is present. The indicated factors
are:
•
generally, the ratio of the rated current/voltage of the side referred to the rated current/voltage of the
instrument transformers at the measuring locations;
•
for differential protection, the ratio of the rated current of the protected object referred to the rated
current of the current transformers at the measuring locations;
•
for restricted earth fault protection, the ratio of the rated current of the assigned side of the protected
object referred to the rated current of the starpoint current transformer.
None of these factors should be greater than 8 or smaller than 0.125. Otherwise, the risk of higher measuring
errors could arise. If a factor is greater than 50 or smaller than 0.02, unexpected reactions of protection func-
tion may occur.
Table 3-30
Indications on matching factors
Message No. Description see
section
Gen CT-M1:
to
Gen CT-M5:
30060
to
30064
General: Magnitude matching factor at the indicated measuring loca-
tion
2.1.4 Power
System Data
1
Gen VT-U1:
30065 General: Magnitude matching factor of 3-phase voltage input 2.1.4 Power
System Data
1
Diff CT-M1:
to
Diff CT-M5:
5733
to
5737
Differential protection: Magnitude matching factor of the indicated
measuring location (3-phase protected objects)
2.1.4 Power
System Data
1
Diff CT-I1:
to
DiffCT-I12:
5721
to
5732
Differential protection: Magnitude matching factor of the indicated
measuring location (1-phase busbar protection)
2.1.4 Power
System Data
1
Mounting and Commissioning
3.3 Commissioning
364 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
