Addr. Parameter Setting Options Default Setting Comments
132 DMT/IDMT Phase3 Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
Disabled DMT / IDMT Phase 3
134 DMT/IDMT 3I0 2 Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
Disabled DMT / IDMT 3I0 2
136 DMT/IDMT 3I0 3 Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
Disabled DMT / IDMT 3I0 3
138 DMT/IDMT Earth2 Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
Disabled DMT / IDMT Earth 2
140 UNBALANCE LOAD Disabled
Definite Time
TOC IEC
TOC ANSI
DT/thermal
Disabled Unbalance Load (Negative
Sequence)
142 THERM. OVERLOAD Disabled
th rep w.o. sen
th repl w. sens
IEC354
Disabled Thermal Overload Protection
143 OVEREXC. PROT. Disabled
Enabled
Disabled Overexcitation Protection (U/f)
144 THERM.OVERLOAD2 Disabled
th rep w.o. sen
th repl w. sens
IEC354
Disabled Thermal Overload Protection 2
150 REVERSE POWER Disabled
Enabled
Disabled Reverse Power Protection
151 FORWARD POWER Disabled
Enabled
Disabled Forward Power Supervision
152 UNDERVOLTAGE Disabled
Enabled
Disabled Undervoltage Protection
153 OVERVOLTAGE Disabled
Enabled
Disabled Overvoltage Protection
Functions
2.1 General
38 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
