Addr. Parameter Setting Options Default Setting Comments
156 FREQUENCY Prot. Disabled
Enabled
Disabled Over / Underfrequency Protection
170 BREAKER FAILURE Disabled
Enabled
Disabled Breaker Failure Protection
171 BREAKER FAIL. 2 Disabled
Enabled
Disabled Breaker Failure Protection 2
180 DISCON.MEAS.LOC Disabled
Enabled
Disabled Disconnect measurment location
181 M.V. SUPERV Disabled
Enabled
Enabled Measured Values Supervision
182 Trip Cir. Sup. Disabled
2 Binary Inputs
1 Binary Input
Disabled Trip Circuit Supervision
186 EXT. TRIP 1 Disabled
Enabled
Disabled External Trip Function 1
187 EXT. TRIP 2 Disabled
Enabled
Disabled External Trip Function 2
190 RTD-BOX INPUT Disabled
Port C
Port D
Disabled External Temperature Input
191 RTD CONNECTION 6 RTD simplex
6 RTD HDX
12 RTD HDX
6 RTD simplex Ext. Temperature Input Connec-
tion Type
- FLEXIBLE FcT. 1...12 Flexible Function 01
Flexible Function 02
Flexible Function 03
Flexible Function 04
Flexible Function 05
Flexible Function 06
Flexible Function 07
Flexible Function 08
Flexible Function 09
Flexible Function 10
Flexible Function 11
Flexible Function 12
Please select Flexible Functions 1...12
Functions
2.1 General
SIPROTEC 4, 7UT6x, Manual 39
C53000-G1176-C230-5, Edition 09.2016
