Address 225 ASSIGNM. 4M,4S appears if 4 assigned measuring locations (address 212) have been selected
for 4 sides (address 213). Only one option is possible:
•
M1,M2,M3,M4, i.e. the 4 measuring locations are assigned: M1 to side S1, M2 to side S2, M3 to side S3,
M4 to side S4.
Address 226 ASSIGNM. 5M,2S appears if 5 assigned measuring locations (address 212) have been selected
for 2 sides (address 213). The following options are possible:
•
M1+M2+M3,M4+M5, i.e. the 5 measuring locations are assigned: M1 and M2 and M3 to side S1, M4 and
M5 to side S2.
•
M1+M2,M3+M4+M5, i.e. the 5 measuring locations are assigned: M1 and M2 to side S1, M3 and M4 and
M5 to side S2.
•
M1+M2+M3+M4,M5, i.e. the 5 measuring locations are assigned: M1 and M2 and M3 and M4 to side S1,
M5 to side S2.
•
M1,M2+M3+M4+M5, i.e. the 5 measuring locations are assigned: M1 to side S1, M2 and M3 and M4 and
M5 to side S2.
Address 227 ASSIGNM. 5M,3S appears if 5 assigned measuring locations (address 212) have been selected
for 3 sides (address 213). The following options are possible:
•
M1+M2,M3+M4,M5, i.e. the 5 measuring locations are assigned: M1 and M2 to side S1, M3 and M4 to
side S2, M5 to side S3.
•
M1+M2,M3,M4+M5, i.e. the 5 measuring locations are assigned: M1 and M2 to side S1, M3 to side S2, M4
and M5 to side S3.
•
M1,M2+M3,M4+M5, i.e. the 5 measuring locations are assigned: M1 to side S1, M2 and M3 to side S2, M4
and M5 to side S3.
•
M1+M2+M3,M4,M5, i.e. the 5 measuring locations are assigned: M1 and M2 and M3 to side S1, M4 to
side S2, M5 to side S3.
•
M1,M2+M3+M4,M5, i.e. the 5 measuring locations are assigned: M1 to side S1, M2 and M3 and M4 to
side S2, M5 to side S3.
•
M1,M2,M3+M4+M5, i.e. the 5 measuring locations are assigned: M1 to side S1, M2 to side S2, M3 and M4
and M5 to side S3.
Address 228 ASSIGNM. 5M,4S appears if 5 assigned measuring locations (address 212) have been selected
for 4 sides (address 213). The following options are possible:
•
M1+M2,M3,M4,M5, i.e. the 5 measuring locations are assigned: M1 and M2 to side S1, M3 to side S2, M4
to side S3, M5 to side S4.
•
M1,M2+M3,M4,M5, i.e. the 5 measuring locations are assigned: M1 to side S1, M2 and M3 to side S2, M4
to side S3, M5 to side S4.
•
M1,M2,M3+M4,M5, i.e. the 5 measuring locations are assigned: M1 to side S1, M2 to side S2, M3 and M4
to side S3, M5 to side S4.
•
M1,M2,M3,M4+M5, i.e. the 5 measuring locations are assigned: M1 to side S1, M2 to side S2, M3 to side
S3, M4 and M5 to side S4.
Address 229 ASSIGNM. 5M,5S appears if 5 assigned measuring locations (address 212) have been selected
for 5 sides (address 213). Only one option is possible:
•
M1,M2,M3,M4,M5, i.e. the 5 measuring locations are assigned: M1 to side S1, M2 to side S2, M3 to side
S3, M4 to side S4, M5 to side S5.
Assignment of Sides in Auto-Transformers
If auto-transformers are protected the additional question arises how the sides of the protected object are to
be handled by the main protection function, the differential protection. As mentioned above, various possibili-
ties exist how the sides are defined. Further information is necessary in order to achieve an exact replica of the
auto-transformer. Therefore, the following addresses only apply to auto-transformers (address 105 PROT.
OBJECT = Autotransf. or Autotr. node).
Functions
2.1 General
50 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
