Addr. Parameter Function C Setting Options Default Setting Comments
0 P.U. THRESHOLD Flx 1.0 .. 170.0 V 110.0 V Pickup Threshold
0 P.U. THRESHOLD Flx 1.0 .. 170.0 V 110.0 V Pickup Threshold
0 P.U. THRESHOLD Flx 40.00 .. 66.00 Hz 51.00 Hz Pickup Threshold
0 P.U. THRESHOLD Flx 10.00 .. 22.00 Hz 18.00 Hz Pickup Threshold
0 P.U. THRESHOLD Flx 1A 1.7 .. 3000.0 W 200.0 W Pickup Threshold
5A 8.5 .. 15000.0 W 1000.0 W
0 Pick-up thresh. Flx 0.01 .. 17.00 P/SnS 1.10 P/SnS Pick-up threshold P-side
0 Pick-up thresh. Flx 1A 1.7 .. 3000.0 VAR 200.0 VAR Pick-up threshold Q meas.
location
5A 8.5 .. 15000.0 VAR 1000.0 VAR
0 Pick-up thresh. Flx 0.01 .. 17.00 Q/SnS 1.10 Q/SnS Pick-up threshold Q-side
0 P.U. THRESHOLD Flx -0.99 .. 0.99 0.50 Pickup Threshold
0 T TRIP DELAY Flx 0.00 .. 3600.00 sec 1.00 sec Trip Time Delay
0A T PICKUP DELAY Flx 0.00 .. 60.00 sec 0.00 sec Pickup Time Delay
0A T DROPOUT DELAY Flx 0.00 .. 60.00 sec 0.00 sec Dropout Time Delay
0A BLOCKED BY FFM Flx YES
NO
YES Block in case of Meas.-
Voltage Loss
0A Blk I brkn cond Flx YES
NO
YES Block for broken
conductor in CT path
0A DROPOUT RATIO Flx 0.70 .. 0.99 0.95 Dropout Ratio
0A DROPOUT RATIO Flx 1.01 .. 3.00 1.05 Dropout Ratio
0 Function addMV MinMax
Dmd
Min/Max/Dmd
Dmd+MiMaD
MiMa/Dmd+MiMaD
MinMax Scope of the extended
measuring values
0 Input Meas. Val addMV (Einstellmöglich-
keiten anwendung-
sabhängig)
none Input measured value
0 Reset Meas. Val addMV (Einstellmöglich-
keiten anwendung-
sabhängig)
>Reset MinMax Reset of ext. meas. values
in progress
201 FltDisp.LED/LCD Device Target on PU
Target on TRIP
Target on PU Fault Display on LED / LCD
202 Spont. FltDisp. Device NO
YES
NO Spontaneous display of
flt.annunciations
204 Start image DD Device image 1
image 2
image 3
image 4
image 5
image 6
image 7
image 1 Start image Default
Display
211 No Conn.MeasLoc P.System Data
1
2
3
4
5
3 Number of connected
Measuring Locations
Functions, Settings, Information
F.2 Settings
546 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
