Addr. Parameter Function C Setting Options Default Setting Comments
212 No AssigMeasLoc P.System Data
1
2
3
4
5
3 Number of assigned
Measuring Locations
213 NUMBER OF SIDES P.System Data
1
2
3
4
5
3 Number of Sides
216 NUMBER OF ENDS P.System Data
1
3
4
5
6
7
8
9
10
11
12
6 Number of Ends for 1
Phase Busbar
220 ASSIGNM. 2M,2S P.System Data
1
M1,M2 M1,M2 Assignment at 2
assig.Meas.Loc./ 2 Sides
221 ASSIGNM. 3M,2S P.System Data
1
M1+M2,M3
M1,M2+M3
M1+M2,M3 Assignment at 3
assig.Meas.Loc./ 2 Sides
222 ASSIGNM. 3M,3S P.System Data
1
M1,M2,M3 M1,M2,M3 Assignment at 3
assig.Meas.Loc./ 3 Sides
223 ASSIGNM. 4M,2S P.System Data
1
M1+M2,M3+M4
M1+M2+M3,M4
M1,M2+M3+M4
M1+M2,M3+M4 Assignment at 4
assig.Meas.Loc./ 2 Sides
224 ASSIGNM. 4M,3S P.System Data
1
M1+M2,M3,M4
M1,M2+M3,M4
M1,M2,M3+M4
M1+M2,M3,M4 Assignment at 4
assig.Meas.Loc./ 3 Sides
225 ASSIGNM. 4M,4S P.System Data
1
M1,M2,M3,M4 M1,M2,M3,M4 Assignment at 4
assig.Meas.Loc./ 4 Sides
226 ASSIGNM. 5M,2S P.System Data
1
M1+M2+M3,M4+M
5
M1+M2,M3+M4+M
5
M1+M2+M3+M4,M
5
M1,M2+M3+M4+M
5
M1+M2+M3,M4+M
5
Assignment at 5
assig.Meas.Loc./ 2 Sides
227 ASSIGNM. 5M,3S P.System Data
1
M1+M2,M3+M4,M5
M1+M2,M3,M4+M5
M1,M2+M3,M4+M5
M1+M2+M3,M4,M5
M1,M2+M3+M4,M5
M1,M2,M3+M4+M5
M1+M2,M3+M4,M5 Assignment at 5
assig.Meas.Loc./ 3 Sides
Functions, Settings, Information
F.2 Settings
SIPROTEC 4, 7UT6x, Manual 547
C53000-G1176-C230-5, Edition 09.2016
