Addr. Parameter Function C Setting Options Default Setting Comments
228 ASSIGNM. 5M,4S P.System Data
1
M1+M2,M3,M4,M5
M1,M2+M3,M4,M5
M1,M2,M3+M4,M5
M1,M2,M3,M4+M5
M1+M2,M3,M4,M5 Assignment at 5
assig.Meas.Loc./ 4 Sides
229 ASSIGNM. 5M,5S P.System Data
1
M1,M2,M3,M4,M5 M1,M2,M3,M4,M5 Assignment at 5
assig.Meas.Loc./ 5 Sides
230 ASSIGNM. ERROR P.System Data
1
No AssigMeasLoc
No of sides
without Assignment Error
241 SIDE 1 P.System Data
1
auto-connected auto-connected Side 1 is assigned to
242 SIDE 2 P.System Data
1
auto-connected auto-connected Side 2 is assigned to
243 SIDE 3 P.System Data
1
auto-connected
compensation
earth.electrode
auto-connected Side 3 is assigned to
244 SIDE 4 P.System Data
1
auto-connected
compensation
earth.electrode
compensation Side 4 is assigned to
251 AUX. CT IX1 P.System Data
1
Not connected
conn/not assig.
Side 1 earth
Side 2 earth
Side 3 earth
Side 4 earth
MeasLoc.1 earth
MeasLoc.2 earth
MeasLoc.3 earth
MeasLoc.4 earth
Not connected Auxiliary CT IX1 is used as
252 AUX. CT IX2 P.System Data
1
Not connected
conn/not assig.
Side 1 earth
Side 2 earth
Side 3 earth
Side 4 earth
MeasLoc.1 earth
MeasLoc.2 earth
MeasLoc.3 earth
MeasLoc.4 earth
Not connected Auxiliary CT IX2 is used as
253 AUX. CT IX3 P.System Data
1
Not connected
conn/not assig.
Side 1 earth
Side 2 earth
Side 3 earth
Side 4 earth
MeasLoc.1 earth
MeasLoc.2 earth
MeasLoc.3 earth
MeasLoc.4 earth
Not connected Auxiliary CT IX3 is used as
Functions, Settings, Information
F.2 Settings
548 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
