No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
023.25
26
Phase L1 InRush picked
up (L1 InRush PU)
Phase O/C OUT * ON
OFF
* LED BO 60 89 2 Yes
023.25
27
Phase L2 InRush picked
up (L2 InRush PU)
Phase O/C OUT * ON
OFF
* LED BO 60 90 2 Yes
023.25
28
Phase L3 InRush picked
up (L3 InRush PU)
Phase O/C OUT * ON
OFF
* LED BO 60 91 2 Yes
023.25
31
Phase L1 InRush detected
(L1 InRush det.)
Phase O/C OUT * ON
OFF
* LED BO
023.25
32
Phase L2 InRush detected
(L2 InRush det.)
Phase O/C OUT * ON
OFF
* LED BO
023.25
33
Phase L3 InRush detected
(L3 InRush det.)
Phase O/C OUT * ON
OFF
* LED BO
023.25
34
Cross blk: PhX blocked
PhY (INRUSH X-BLK)
Phase O/C OUT * ON
OFF
* LED BO
023.25
41
I>> Time Out (I>> Time
Out)
Phase O/C OUT * * * LED BO 60 49 2 Yes
023.25
42
I> Time Out (I> Time Out) Phase O/C OUT * * * LED BO 60 53 2 Yes
023.25
43
Ip Time Out (Ip Time Out) Phase O/C OUT * * * LED BO 60 57 2 Yes
023.25
51
I>> TRIP (I>> TRIP) Phase O/C OUT * ON * LED BO 60 70 2 Yes
023.25
52
I> TRIP (I> TRIP) Phase O/C OUT * ON * LED BO 60 71 2 Yes
023.25
53
Ip TRIP (Ip TRIP) Phase O/C OUT * ON * LED BO 60 58 2 Yes
024.24
04
>BLOCK Earth time over-
current (>BLK Earth O/C)
Earth O/C SP * * * LED BI BO
024.24
11
Time Overcurrent Earth is
OFF (O/C Earth OFF)
Earth O/C OUT O
N
OF
F
* * LED BO 60 26 1 Yes
024.24
12
Time Overcurrent Earth is
BLOCKED (O/C Earth BLK)
Earth O/C OUT O
N
OF
F
ON
OFF
* LED BO 60 27 1 Yes
024.24
13
Time Overcurrent Earth is
ACTIVE (O/C Earth ACT)
Earth O/C OUT O
N
OF
F
* * LED BO 60 28 1 Yes
024.24
25
Time Overcurrent Earth
picked up (O/C Earth PU)
Earth O/C OUT * ON
OFF
m LED BO 60 67 2 Yes
Functions, Settings, Information
F.3 Information List
592 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
