No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
024.24
92
O/C Earth err.: No auxil-
iary CT assigned (O/C
Earth ErrCT)
Earth O/C OUT O
N
* * LED BO
024.25
01
>BLOCK time overcurrent
Earth InRush (>BLK E O/C
Inr)
Earth O/C SP O
N
OF
F
ON
OFF
* LED BI BO 60 10
0
1 Yes
024.25
02
>BLOCK IE>> (>BLOCK
IE>>)
Earth O/C SP * * * LED BI BO 60 4 1 Yes
024.25
03
>BLOCK IE> (>BLOCK IE>) Earth O/C SP * * * LED BI BO 60 5 1 Yes
024.25
04
>BLOCK IEp (>BLOCK IEp) Earth O/C SP * * * LED BI BO 60 6 1 Yes
024.25
14
IE>> BLOCKED (IE>>
BLOCKED)
Earth O/C OUT O
N
OF
F
ON
OFF
* LED BO 60 10
8
1 Yes
024.25
15
IE> BLOCKED (IE>
BLOCKED)
Earth O/C OUT O
N
OF
F
ON
OFF
* LED BO 60 10
7
1 Yes
024.25
16
IEp BLOCKED (IEp
BLOCKED)
Earth O/C OUT O
N
OF
F
ON
OFF
* LED BO 60 11
0
1 Yes
024.25
21
IE>> picked up (IE>>
picked up)
Earth O/C OUT * ON
OFF
* LED BO 60 59 2 Yes
024.25
22
IE> picked up (IE> picked
up)
Earth O/C OUT * ON
OFF
* LED BO 60 62 2 Yes
024.25
23
IEp picked up (IEp picked
up)
Earth O/C OUT * ON
OFF
* LED BO 60 64 2 Yes
024.25
24
IE> InRush picked up (IE>
InRush PU)
Earth O/C OUT * ON
OFF
* LED BO 60 81 2 Yes
024.25
25
IEp InRush picked up (IEp
InRush PU)
Earth O/C OUT * ON
OFF
* LED BO 60 83 2 Yes
024.25
29
Earth InRush picked up
(Earth InRush PU)
Earth O/C OUT * ON
OFF
* LED BO 60 88 2 Yes
024.25
41
IE>> Time Out (IE>> Time
Out)
Earth O/C OUT * * * LED BO 60 60 2 Yes
024.25
42
IE> Time Out (IE> Time
Out)
Earth O/C OUT * * * LED BO 60 63 2 Yes
024.25
43
IEp Time Out (IEp
TimeOut)
Earth O/C OUT * * * LED BO 60 65 2 Yes
Functions, Settings, Information
F.3 Information List
SIPROTEC 4, 7UT6x, Manual 593
C53000-G1176-C230-5, Edition 09.2016
