Siemens SIPROTEC 4 7UT6 Series User Manual

No. Description Function IEC 60870-5-103 Configurable in
Matrix
Type
information number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
644 Frequency (Freq=) Measurement - - - - - CFC CD DD
645 S (apparent power) (S =) Measurement - - - - - CFC CD DD
721 Operat. meas. current IL1 side 1
(IL1S1=)
Measurement 134 139 No 9 1 CFC CD DD
722 Operat. meas. current IL2 side 1
(IL2S1=)
Measurement 134 139 No 9 5 CFC CD DD
723 Operat. meas. current IL3 side 1
(IL3S1=)
Measurement 134 139 No 9 3 CFC CD DD
724 Operat. meas. current IL1 side 2
(IL1S2=)
Measurement 134 139 No 9 2 CFC CD DD
725 Operat. meas. current IL2 side 2
(IL2S2=)
Measurement 134 139 No 9 6 CFC CD DD
726 Operat. meas. current IL3 side 2
(IL3S2=)
Measurement 134 139 No 9 4 CFC CD DD
727 Operat. meas. current IL1 side 3
(IL1S3=)
Measurement - - - - - CFC CD DD
728 Operat. meas. current IL2 side 3
(IL2S3=)
Measurement - - - - - CFC CD DD
729 Operat. meas. current IL3 side 3
(IL3S3=)
Measurement - - - - - CFC CD DD
765 (U/Un) / (f/fn) (U/f =) Measurement - - - - - CFC CD DD
766 Calculated temperature (U/f) (U/f
th. =)
Meas. Thermal - - - - - CFC CD DD
888 Pulsed Energy Wp (active)
(Wp(puls)=)
Energy 133 55 No 205 - CD DD
889 Pulsed Energy Wq (reactive)
(Wq(puls)=)
Energy 133 56 No 205 - CD DD
901 Power Factor (PF =) Measurement - - - - - CFC CD DD
910 Calculated rotor temp. (unbal.
load) (ThermRep.=)
Meas. Thermal - - - - - CFC CD DD
924 Wp Forward (Wp+=) Energy 133 51 No 205 - CD DD
925 Wq Forward (Wq+=) Energy 133 52 No 205 - CD DD
928 Wp Reverse (Wp-=) Energy 133 53 No 205 - CD DD
929 Wq Reverse (Wq-=) Energy 133 54 No 205 - CD DD
1068 Temperature of RTD 1 (Θ RTD 1 =) Meas. Thermal 134 146 No 9 1 CFC CD DD
1069 Temperature of RTD 2 (Θ RTD 2 =) Meas. Thermal 134 146 No 9 2 CFC CD DD
1070 Temperature of RTD 3 (Θ RTD 3 =) Meas. Thermal 134 146 No 9 3 CFC CD DD
1071 Temperature of RTD 4 (Θ RTD 4 =) Meas. Thermal 134 146 No 9 4 CFC CD DD
1072 Temperature of RTD 5 (Θ RTD 5 =) Meas. Thermal 134 146 No 9 5 CFC CD DD
1073 Temperature of RTD 6 (Θ RTD 6 =) Meas. Thermal 134 146 No 9 6 CFC CD DD
1074 Temperature of RTD 7 (Θ RTD 7 =) Meas. Thermal 134 146 No 9 7 CFC CD DD
1075 Temperature of RTD 8 (Θ RTD 8 =) Meas. Thermal 134 146 No 9 8 CFC CD DD
Functions, Settings, Information
F.5 Measured Values
658 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
