No. Description Function IEC 60870-5-103 Configurable in
Matrix
Type
information number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
1076 Temperature of RTD 9 (Θ RTD 9 =) Meas. Thermal 134 146 No 9 9 CFC CD DD
1077 Temperature of RTD10 (Θ RTD10
=)
Meas. Thermal 134 146 No 9 10 CFC CD DD
1078 Temperature of RTD11 (Θ RTD11
=)
Meas. Thermal 134 146 No 9 11 CFC CD DD
1079 Temperature of RTD12 (Θ RTD12
=)
Meas. Thermal 134 146 No 9 12 CFC CD DD
7742 IDiffL1(I/Inominal object [%])
(IDiffL1=)
Meas. Dif/Rest. - - - - - CFC CD DD
7743 IDiffL2(I/Inominal object [%])
(IDiffL2=)
Meas. Dif/Rest. - - - - - CFC CD DD
7744 IDiffL3(I/Inominal object [%])
(IDiffL3=)
Meas. Dif/Rest. - - - - - CFC CD DD
7745 IRestL1(I/Inominal object [%])
(IRestL1=)
Meas. Dif/Rest. - - - - - CFC CD DD
7746 IRestL2(I/Inominal object [%])
(IRestL2=)
Meas. Dif/Rest. - - - - - CFC CD DD
7747 IRestL3(I/Inominal object [%])
(IRestL3=)
Meas. Dif/Rest. - - - - - CFC CD DD
30633 Phase angle of current I1 (φI1=) Measurement - - - - - CFC CD DD
30634 Phase angle of current I2 (φI2=) Measurement - - - - - CFC CD DD
30635 Phase angle of current I3 (φI3=) Measurement - - - - - CFC CD DD
30636 Phase angle of current I4 (φI4=) Measurement - - - - - CFC CD DD
30637 Phase angle of current I5 (φI5=) Measurement - - - - - CFC CD DD
30638 Phase angle of current I6 (φI6=) Measurement - - - - - CFC CD DD
30639 Phase angle of current I7 (φI7=) Measurement - - - - - CFC CD DD
30640 3I0 (zero sequence) of side 1
(3I0S1=)
Measurement - - - - - CFC CD DD
30641 I1 (positive sequence) of side 1
(I1S1=)
Measurement - - - - - CFC CD DD
30642 I2 (negative sequence) of side 1
(I2S1=)
Measurement - - - - - CFC CD DD
30643 3I0 (zero sequence) of side 2
(3I0S2=)
Measurement - - - - - CFC CD DD
30644 I1 (positive sequence) of side 2
(I1S2=)
Measurement - - - - - CFC CD DD
30645 I2 (negative sequence) of side 2
(I2S2=)
Measurement - - - - - CFC CD DD
30646 Operat. meas. current I1 (I1=) Measurement - - - - - CFC CD DD
30647 Operat. meas. current I2 (I2=) Measurement - - - - - CFC CD DD
30648 Operat. meas. current I3 (I3=) Measurement - - - - - CFC CD DD
30649 Operat. meas. current I4 (I4=) Measurement - - - - - CFC CD DD
Functions, Settings, Information
F.5 Measured Values
SIPROTEC 4, 7UT6x, Manual 659
C53000-G1176-C230-5, Edition 09.2016
