No. Description Function IEC 60870-5-103 Configurable in
Matrix
Type
information number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
30650 Operat. meas. current I5 (I5=) Measurement - - - - - CFC CD DD
30651 Operat. meas. current I6 (I6=) Measurement - - - - - CFC CD DD
30652 Operat. meas. current I7 (I7=) Measurement - - - - - CFC CD DD
30653 Operat. meas. current I8 (I8=) Measurement - - - - - CFC CD DD
30656 Operat. meas. voltage Umeas.
(Umeas.=)
Measurement - - - - - CFC CD DD
30661 Operat. meas. current IL1 meas.
loc. 1 (IL1M1=)
Measurement 134 149 No 9 2 CFC CD DD
30662 Operat. meas. current IL2 meas.
loc. 1 (IL2M1=)
Measurement 134 149 No 9 1 CFC CD DD
30663 Operat. meas. current IL3 meas.
loc. 1 (IL3M1=)
Measurement 134 149 No 9 3 CFC CD DD
30664 3I0 (zero sequence) of meas. loc.
1 (3I0M1=)
Measurement - - - - - CFC CD DD
30665 I1 (positive sequence) of meas.
loc. 1 (I1M1=)
Measurement - - - - - CFC CD DD
30666 I2 (negative sequence) of meas.
loc. 1 (I2M1=)
Measurement - - - - - CFC CD DD
30667 Operat. meas. current IL1 meas.
loc. 2 (IL1M2=)
Measurement 134 149 No 9 5 CFC CD DD
30668 Operat. meas. current IL2 meas.
loc. 2 (IL2M2=)
Measurement 134 149 No 9 4 CFC CD DD
30669 Operat. meas. current IL3 meas.
loc. 2 (IL3M2=)
Measurement 134 149 No 9 6 CFC CD DD
30670 3I0 (zero sequence) of meas. loc.
2 (3I0M2=)
Measurement - - - - - CFC CD DD
30671 I1 (positive sequence) of meas.
loc. 2 (I1M2=)
Measurement - - - - - CFC CD DD
30672 I2 (negative sequence) of meas.
loc. 2 (I2M2=)
Measurement - - - - - CFC CD DD
30673 Operat. meas. current IL1 meas.
loc. 3 (IL1M3=)
Measurement 134 149 No 9 8 CFC CD DD
30674 Operat. meas. current IL2 meas.
loc. 3 (IL2M3=)
Measurement 134 149 No 9 7 CFC CD DD
30675 Operat. meas. current IL3 meas.
loc. 3 (IL3M3=)
Measurement 134 149 No 9 9 CFC CD DD
30676 3I0 (zero sequence) of meas. loc.
3 (3I0M3=)
Measurement - - - - - CFC CD DD
30677 I1 (positive sequence) of meas.
loc. 3 (I1M3=)
Measurement - - - - - CFC CD DD
30678 I2 (negative sequence) of meas.
loc. 3 (I2M3=)
Measurement - - - - - CFC CD DD
Functions, Settings, Information
F.5 Measured Values
660 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
