No. Description Function IEC 60870-5-103 Configurable in
Matrix
Type
information number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
30679 Operat. meas. current IL1 meas.
loc. 4 (IL1M4=)
Measurement 134 149 No 9 11 CFC CD DD
30680 Operat. meas. current IL2 meas.
loc. 4 (IL2M4=)
Measurement 134 149 No 9 10 CFC CD DD
30681 Operat. meas. current IL3 meas.
loc. 4 (IL3M4=)
Measurement 134 149 No 9 12 CFC CD DD
30682 3I0 (zero sequence) of meas. loc.
4 (3I0M4=)
Measurement - - - - - CFC CD DD
30683 I1 (positive sequence) of meas.
loc. 4 (I1M4=)
Measurement - - - - - CFC CD DD
30684 I2 (negative sequence) of meas.
loc. 4 (I2M4=)
Measurement - - - - - CFC CD DD
30685 Operat. meas. current IL1 meas.
loc. 5 (IL1M5=)
Measurement 134 149 No 9 14 CFC CD DD
30686 Operat. meas. current IL2 meas.
loc. 5 (IL2M5=)
Measurement 134 149 No 9 13 CFC CD DD
30687 Operat. meas. current IL3 meas.
loc. 5 (IL3M5=)
Measurement 134 149 No 9 15 CFC CD DD
30688 3I0 (zero sequence) of meas. loc.
5 (3I0M5=)
Measurement - - - - - CFC CD DD
30689 I1 (positive sequence) of meas.
loc. 5 (I1M5=)
Measurement - - - - - CFC CD DD
30690 I2 (negative sequence) of meas.
loc. 5 (I2M5=)
Measurement - - - - - CFC CD DD
30713 3I0 (zero sequence) of side 3
(3I0S3=)
Measurement - - - - - CFC CD DD
30714 I1 (positive sequence) of side 3
(I1S3=)
Measurement - - - - - CFC CD DD
30715 I2 (negative sequence) of side 3
(I2S3=)
Measurement - - - - - CFC CD DD
30716 Operat. meas. current IL1 side 4
(IL1S4=)
Measurement - - - - - CFC CD DD
30717 Operat. meas. current IL2 side 4
(IL2S4=)
Measurement - - - - - CFC CD DD
30718 Operat. meas. current IL3 side 4
(IL3S4=)
Measurement - - - - - CFC CD DD
30719 3I0 (zero sequence) of side 4
(3I0S4=)
Measurement - - - - - CFC CD DD
30720 I1 (positive sequence) of side 4
(I1S4=)
Measurement - - - - - CFC CD DD
30721 I2 (negative sequence) of side 4
(I2S4=)
Measurement - - - - - CFC CD DD
30722 Operat. meas. current IL1 side 5
(IL1S5=)
Measurement - - - - - CFC CD DD
Functions, Settings, Information
F.5 Measured Values
SIPROTEC 4, 7UT6x, Manual 661
C53000-G1176-C230-5, Edition 09.2016
