Addr. Parameter Setting Options Default Setting Comments
324 CONNECTION S2 Y
D
Z
Y Transf. Winding Connection Side 2
325 VECTOR GRP S2 0
1
2
3
4
5
6
7
8
9
10
11
0 Vector Group Numeral of Side 2
331 UN-PRI SIDE 3 0.4 .. 800.0 kV 11.0 kV Rated Primary Voltage Side 3
332 SN SIDE 3 0.20 .. 5000.00 MVA 10.00 MVA Rated Apparent Power of Transf.
Side 3
333 STARPNT SIDE 3 Earthed
Isolated
Earthed Starpoint of Side 3 is
334 CONNECTION S3 Y
D
Z
Y Transf. Winding Connection Side 3
335 VECTOR GRP S3 0
1
2
3
4
5
6
7
8
9
10
11
0 Vector Group Numeral of Side 3
341 UN-PRI SIDE 4 0.4 .. 800.0 kV 11.0 kV Rated Primary Voltage Side 4
342 SN SIDE 4 0.20 .. 5000.00 MVA 10.00 MVA Rated Apparent Power of Transf.
Side 4
343 STARPNT SIDE 4 Earthed
Isolated
Earthed Starpoint of Side 4 is
344 CONNECTION S4 Y
D
Z
Y Transf. Winding Connection Side 4
Functions
2.1 General
76 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
