Addr. Parameter Setting Options Default Setting Comments
345 VECTOR GRP S4 0
1
2
3
4
5
6
7
8
9
10
11
0 Vector Group Numeral of Side 4
351 UN-PRI SIDE 5 0.4 .. 800.0 kV 11.0 kV Rated Primary Voltage Side 5
352 SN SIDE 5 0.20 .. 5000.00 MVA 10.00 MVA Rated Apparent Power of Transf.
Side 5
353 STARPNT SIDE 5 Earthed
Isolated
Earthed Starpoint of Side 5 is
354 CONNECTION S5 Y
D
Z
Y Transf. Winding Connection Side 5
355 VECTOR GRP S5 0
1
2
3
4
5
6
7
8
9
10
11
0 Vector Group Numeral of Side 5
361 UN GEN/MOTOR 0.4 .. 800.0 kV 21.0 kV Rated Primary Voltage Generator/
Motor
362 SN GEN/MOTOR 0.20 .. 5000.00 MVA 70.00 MVA Rated Apparent Power of the
Generator
370 UN BUSBAR 0.4 .. 800.0 kV 110.0 kV Rated Primary Voltage Busbar
371 I PRIMARY OP. 1 .. 100000 A 200 A Primary Operating Current of
Busbar
372 I PRIMARY OP S1 1 .. 100000 A 200 A Primary Operating Current Side 1
373 I PRIMARY OP S2 1 .. 100000 A 200 A Primary Operating Current Side 2
374 I PRIMARY OP S3 1 .. 100000 A 200 A Primary Operating Current Side 3
375 I PRIMARY OP S4 1 .. 100000 A 200 A Primary Operating Current Side 4
376 I PRIMARY OP S5 1 .. 100000 A 200 A Primary Operating Current Side 5
381 I PRIMARY OP 1 1 .. 100000 A 200 A Primary Operating Current End 1
382 I PRIMARY OP 2 1 .. 100000 A 200 A Primary Operating Current End 2
383 I PRIMARY OP 3 1 .. 100000 A 200 A Primary Operating Current End 3
384 I PRIMARY OP 4 1 .. 100000 A 200 A Primary Operating Current End 4
Functions
2.1 General
SIPROTEC 4, 7UT6x, Manual 77
C53000-G1176-C230-5, Edition 09.2016
