Addr. Parameter Setting Options Default Setting Comments
385 I PRIMARY OP 5 1 .. 100000 A 200 A Primary Operating Current End 5
386 I PRIMARY OP 6 1 .. 100000 A 200 A Primary Operating Current End 6
387 I PRIMARY OP 7 1 .. 100000 A 200 A Primary Operating Current End 7
388 I PRIMARY OP 8 1 .. 100000 A 200 A Primary Operating Current End 8
389 I PRIMARY OP 9 1 .. 100000 A 200 A Primary Operating Current End 9
390 I PRIMARY OP 10 1 .. 100000 A 200 A Primary Operating Current End 10
391 I PRIMARY OP 11 1 .. 100000 A 200 A Primary Operating Current End 11
392 I PRIMARY OP 12 1 .. 100000 A 200 A Primary Operating Current End 12
396 PHASE SELECTION Phase 1
Phase 2
Phase 3
Phase 1 Phase selection
403 I PRIMARY OP M3 1 .. 100000 A 200 A Primary Operating Current Meas.
Loc. 3
404 I PRIMARY OP M4 1 .. 100000 A 200 A Primary Operating Current Meas.
Loc. 4
405 I PRIMARY OP M5 1 .. 100000 A 200 A Primary Operating Current Meas.
Loc. 5
408 UN-PRI M3 0.4 .. 800.0 kV 110.0 kV Rated Primary Voltage Measuring
Loc. 3
409 UN-PRI U4 0.4 .. 800.0 kV 110.0 kV Rated Primary Voltage U4
413 REF PROT. AT Side 1
Side 2
Side 3
Side 4
Side 5
auto-connected
n.assigMeasLoc3
n.assigMeasLoc4
n.assigMeasLoc5
Side 1 Restricted earth fault prot.
assigned to
414 REF PROT. 2 AT Side 1
Side 2
Side 3
Side 4
Side 5
auto-connected
n.assigMeasLoc3
n.assigMeasLoc4
n.assigMeasLoc5
Side 1 Restricted earth fault prot2
assigned to
420 DMT/IDMT Ph AT Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Side 1 DMT / IDMT Phase assigned to
Functions
2.1 General
78 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
