Siemens SIPROTEC 4 7UT6 Series User Manual

Addr. Parameter Setting Options Default Setting Comments
422 DMT/IDMT 3I0 AT Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Side 1 DMT / IDMT 3I0 assigned to
424 DMT/IDMT E AT no assig. poss.
AuxiliaryCT IX1
AuxiliaryCT IX2
AuxiliaryCT IX3
AuxiliaryCT IX4
AuxiliaryCT IX1 DMT / IDMT Earth assigned to
427 DMT 1PHASE AT no assig. poss.
AuxiliaryCT IX1
AuxiliaryCT IX2
AuxiliaryCT IX3
AuxiliaryCT IX4
AuxiliaryCT IX1 DMT 1Phase assigned to
430 DMT/IDMT Ph2 AT Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Side 1 DMT / IDMT Phase 2 assigned to
432 DMT/IDMT Ph3 AT Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Side 1 DMT / IDMT Phase 3 assigned to
Functions
2.1 General
SIPROTEC 4, 7UT6x, Manual 79
C53000-G1176-C230-5, Edition 09.2016
