Addr. Parameter Setting Options Default Setting Comments
470 BREAKER FAIL.AT Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Ext. switchg. 1
Side 1 Breaker Failure Protection
assigned to
471 BREAKER FAIL2AT Side 1
Side 2
Side 3
Side 4
Side 5
Measuring loc.1
Measuring loc.2
Measuring loc.3
Measuring loc.4
Measuring loc.5
Ext. switchg. 1
Side 1 Breaker Failure Protection 2
assigned to
511 STRPNT->OBJ M1 YES
NO
YES CT-Strpnt. Meas. Loc.1 in Dir. of
Object
512 IN-PRI CT M1 1 .. 100000 A 200 A CT Rated Primary Current Meas.
Loc. 1
513 IN-SEC CT M1 1A
5A
1A CT Rated Secondary Current Meas.
Loc. 1
521 STRPNT->OBJ M2 YES
NO
YES CT-Strpnt. Meas. Loc.2 in Dir. of
Object
522 IN-PRI CT M2 1 .. 100000 A 2000 A CT Rated Primary Current Meas.
Loc. 2
523 IN-SEC CT M2 1A
5A
1A CT Rated Secondary Current Meas.
Loc. 2
531 STRPNT->OBJ M3 YES
NO
YES CT-Strpnt. Meas. Loc.3 in Dir. of
Object
532 IN-PRI CT M3 1 .. 100000 A 2000 A CT Rated Primary Current Meas.
Loc. 3
533 IN-SEC CT M3 1A
5A
1A CT Rated Secondary Current Meas.
Loc. 3
541 STRPNT->OBJ M4 YES
NO
YES CT-Strpnt. Meas. Loc.4 in Dir. of
Object
542 IN-PRI CT M4 1 .. 100000 A 2000 A CT Rated Primary Current Meas.
Loc. 4
543 IN-SEC CT M4 1A
5A
1A CT Rated Secondary Current Meas.
Loc. 4
551 STRPNT->OBJ M5 YES
NO
YES CT-Strpnt. Meas. Loc.5 in Dir. of
Object
Functions
2.1 General
SIPROTEC 4, 7UT6x, Manual 81
C53000-G1176-C230-5, Edition 09.2016
