Addr. Parameter Setting Options Default Setting Comments
552 IN-PRI CT M5 1 .. 100000 A 2000 A CT Rated Primary Current Meas.
Loc. 5
553 IN-SEC CT M5 1A
5A
1A CT Rated Secondary Current Meas.
Loc. 5
561 STRPNT->BUS I1 YES
NO
YES CT-Starpoint I1 in Direction of
Busbar
562 IN-PRI CT I1 1 .. 100000 A 200 A CT Rated Primary Current I1
563 IN-SEC CT I1 1A
5A
0.1A
1A CT Rated Secondary Current I1
571 STRPNT->BUS I2 YES
NO
YES CT-Starpoint I2 in Direction of
Busbar
572 IN-PRI CT I2 1 .. 100000 A 200 A CT Rated Primary Current I2
573 IN-SEC CT I2 1A
5A
0.1A
1A CT Rated Secondary Current I2
581 STRPNT->BUS I3 YES
NO
YES CT-Starpoint I3 in Direction of
Busbar
582 IN-PRI CT I3 1 .. 100000 A 200 A CT Rated Primary Current I3
583 IN-SEC CT I3 1A
5A
0.1A
1A CT Rated Secondary Current I3
591 STRPNT->BUS I4 YES
NO
YES CT-Starpoint I4 in Direction of
Busbar
592 IN-PRI CT I4 1 .. 100000 A 200 A CT Rated Primary Current I4
593 IN-SEC CT I4 1A
5A
0.1A
1A CT Rated Secondary Current I4
601 STRPNT->BUS I5 YES
NO
YES CT-Starpoint I5 in Direction of
Busbar
602 IN-PRI CT I5 1 .. 100000 A 200 A CT Rated Primary Current I5
603 IN-SEC CT I5 1A
5A
0.1A
1A CT Rated Secondary Current I5
611 STRPNT->BUS I6 YES
NO
YES CT-Starpoint I6 in Direction of
Busbar
612 IN-PRI CT I6 1 .. 100000 A 200 A CT Rated Primary Current I6
613 IN-SEC CT I6 1A
5A
0.1A
1A CT Rated Secondary Current I6
621 STRPNT->BUS I7 YES
NO
YES CT-Starpoint I7 in Direction of
Busbar
622 IN-PRI CT I7 1 .. 100000 A 200 A CT Rated Primary Current I7
623 IN-SEC CT I7 1A
5A
0.1A
1A CT Rated Secondary Current I7
631 STRPNT->BUS I8 YES
NO
YES CT-Starpoint I8 in Direction of
Busbar
Functions
2.1 General
82 SIPROTEC 4, 7UT6x, Manual
C53000-G1176-C230-5, Edition 09.2016
