Jumper Nominal Voltage
DC 24 V/ 48 V DC 60 V to 125 V DC 110 V to 250 V,
AC 115 V to 230 V
X53 Not used 1-2 2-3
cannot be changed interchangeable
Pickup Voltages of BI1 to BI3
Table 3-5 Jumper settings for the pickup voltages of the binary inputs BI1 to BI3 on the processor board
A–CPU for 7SJ62.../EE
Binary Inputs Jumper
DC 19 V Pickup
1)
DC 88 V Pickup
3)
BI1 X21 L H
BI2 X22 L H
BI3 X23 L H
1)
Factory settings for devices with power supply voltages of DC 24 V to 125 V
2)
Factory settings for devices with power supply voltages of DC 110 V to 220 V and AC 115 V/ 230 V
Contact Mode for Binary Outputs BO1 and BO2
Table 3-6 Jumper settings for the contact mode of the relays BO1 to BO2 on the processor board A–CPU
for7SJ62.../EE
for Jumper Open in quiescent state
(NO)
Closed in quiescent state
(NC)
Presetting
BO1 X41 1-2 2-3 1-2
BO2 X42 1-2 2-3 1-2
Mounting and Commissioning
3.1 Mounting and Connections
380 SIPROTEC 4, 7SJ62/64, Manual
C53000-G1140-C207-8, Edition 08.2016
