Page #395 background image
Bus Address
Table 3-22
Jumper settings of Bus Addresses of input/output boards B-I/O-2 for 7SJ64 housing size
1
/
2
Jumper Mounting Location
Mounting Location
Slot 19
X71 1-2
X72 2-3
X73 1-2
Table 3-23
Jumper settings of Bus Addresses of input/output boards B-I/O-2 for 7SJ64 housing size
1
/
1
Jumper Mounting Location
Slot 19 right side Slot 33 left side
X71 2-3 1-2
X72 1-2 2-3
X73 1-2 1-2
Mounting and Commissioning
3.1 Mounting and Connections
SIPROTEC 4, 7SJ62/64, Manual 395
C53000-G1140-C207-8, Edition 08.2016
